Description

The TEK Resilient Seated Gate Valve is a double flange ductile iron gate valve designed for reliable isolation and shut-off applications in potable water distribution, water treatment plants, sewerage systems, reservoirs, and other municipal water infrastructure. Featuring a resilient EPDM rubber-coated wedge and non-rising stem design, the valve provides bubble-tight sealing, low operating torque, and long service life with minimal maintenance.

Manufactured in accordance with BS 5163-1:2004 and BS EN 1074-2, the valve is engineered to deliver dependable performance under working pressures up to PN16 (16 Bar). Its ductile iron body is protected with Fusion Bonded Epoxy (FBE) coating to provide excellent corrosion resistance for underground and above-ground installations.

The resilient seated wedge minimizes leakage while reducing wear on sealing surfaces, making the valve ideal for long-term operation in clean water systems. The robust stainless steel stem and corrosion-resistant internal components ensure smooth operation and reliable performance even under demanding service conditions.

Features

• Double flange resilient seated gate valve
• Non-rising stem (NRS) design
• Bubble-tight EPDM resilient wedge
• Ductile iron body and bonnet
• Stainless steel stem for corrosion resistance
• Fusion Bonded Epoxy (FBE) coating (minimum 250 μm)
• Low operating torque
• Full bore design for minimal pressure loss
• Suitable for underground and above-ground installation
• Long service life with minimal maintenance
• Easy operation and reliable shut-off
• Designed for potable water applications

Applications

• Potable Water Distribution
• Water Transmission Pipelines
• Water Treatment Plants
• Sewerage Systems
• Pumping Stations
• Reservoirs
• Municipal Water Networks
• Industrial Water Systems
• Irrigation Systems
• Fire Protection Water Lines

Technical Advantages

• Size Range: DN50 – DN600
• Pressure Rating: PN16 (16 Bar)
• Design Standard: BS 5163-1:2004
• Performance Standard: BS EN 1074-2
• Valve Type: Resilient Seated Gate Valve
• Stem Design: Non-Rising Stem (NRS)
• Body Material: Ductile Iron (BS EN 1563 Grade 500/7)
• Wedge: Ductile Iron Fully Vulcanized with EPDM Rubber
• Stem Material: Stainless Steel Grade 431
• Stem Nut: Gunmetal
• Coating: Fusion Bonded Epoxy (Minimum 250 Microns DFT)
• End Connection: Double Flange PN16

Typical Media

• Potable Water
• Clean Water
• Raw Water
• Treated Water
• Industrial Water
• Irrigation Water
• Non-Corrosive Liquids
