Description

The TEK Kinetic Air Relief Valve is a ductile iron single orifice air valve designed to automatically release large volumes of air during pipeline filling and admit air rapidly during pipeline draining or sudden pressure drops. It helps eliminate air pockets, prevent vacuum formation, and protect pipelines from collapse or water hammer, ensuring safe and efficient system operation.

Designed in accordance with JKR 20200-0097-01 and ANSI/AWWA C512, the valve is suitable for potable water transmission lines, pumping stations, reservoirs, irrigation systems, and municipal water distribution networks. The removable cover casing allows easy inspection and maintenance of the float assembly without removing the valve from the pipeline.

Manufactured from high-quality ductile iron with a Fusion Bonded Epoxy (FBE) coating, the valve offers excellent corrosion resistance and long service life in demanding water infrastructure applications.

Features

• Single orifice kinetic air relief valve
• Automatic large-volume air release
• Rapid air intake during pipeline draining
• Prevents vacuum formation and water hammer
• Removable cover for easy maintenance
• Ductile iron body construction
• Stainless steel fasteners
• Fusion Bonded Epoxy (FBE) coating
• Corrosion-resistant design
• Low maintenance requirements
• Flanged connection
• Suitable for potable water applications

Applications

• Water Transmission Pipelines
• Water Distribution Networks
• Pumping Stations
• Water Treatment Plants
• Reservoirs
• Irrigation Systems
• Municipal Water Supply
• Industrial Water Systems
• Pipeline Filling & Draining Systems
• Water Infrastructure Projects

Technical Advantages

• Size Range: DN50 – DN250
• Valve Type: Kinetic Air Relief Valve
• Working Pressure: PN16 (16 Bar)
• Standard: JKR 20200-0097-01 / ANSI/AWWA C512
• Body Material: Ductile Iron
• Float Material: ABS
• Fasteners: Stainless Steel
• Coating: Fusion Bonded Epoxy (Minimum 250 Microns DFT)
• Flange Drilling: BS 4504 PN16 (other standards available upon request)
• Removable cover for simplified inspection and maintenance

Typical Media

• Potable Water
• Clean Water
• Raw Water
• Treated Water
• Industrial Water
• Irrigation Water
• Non-Corrosive Liquids
