Description

The TEK Resilient Seated Gate Valve is a heavy-duty double flange ductile iron gate valve specifically designed for large-diameter water transmission pipelines, water treatment plants, pumping stations, reservoirs, and municipal infrastructure. Featuring a resilient EPDM rubber-coated wedge and non-rising stem design, the valve provides reliable bubble-tight sealing, low operating torque, and long service life under demanding operating conditions.

Manufactured in accordance with BS EN 1171:2002 and BS EN 1074-2, the valve is suitable for working pressures up to PN16 (16 Bar). The ductile iron body is protected with Fusion Bonded Epoxy (FBE) coating to provide superior corrosion resistance for underground and above-ground water systems.

Designed for large-scale water distribution networks, the resilient seated wedge minimizes leakage while reducing wear on sealing surfaces. The robust stainless steel stem and high-quality internal components ensure dependable operation, easy maintenance, and extended service life.

Features

• Heavy-duty double flange gate valve
• Non-rising stem (NRS) design
• EPDM resilient seated wedge
• Ductile iron body and bonnet
• Stainless steel stem
• Fusion Bonded Epoxy (FBE) coating (minimum 250 μm)
• Low operating torque
• Bubble-tight shut-off performance
• Full bore design for minimal pressure loss
• Suitable for large-diameter pipelines
• Long service life with minimal maintenance
• Designed for potable water and municipal applications

Applications

• Water Transmission Pipelines
• Water Treatment Plants
• Pumping Stations
• Reservoirs
• Municipal Water Networks
• Irrigation Systems
• Industrial Water Supply
• Sewerage Infrastructure
• Fire Protection Water Systems
• Large Diameter Pipeline Isolation

Technical Advantages

• Size Range: DN700 – DN1200
• Pressure Rating: PN16 (16 Bar)
• Design Standard: BS EN 1171:2002
• Performance Standard: BS EN 1074-2
• Valve Type: Resilient Seated Gate Valve
• Stem Design: Non-Rising Stem (NRS)
• Body Material: Ductile Iron
• Wedge Material: Ductile Iron Fully Vulcanized with EPDM Rubber
• Stem Material: Stainless Steel
• Coating: Fusion Bonded Epoxy (Minimum 250 Microns DFT)
• End Connection: Double Flange PN16

Typical Media

• Potable Water
• Clean Water
• Raw Water
• Treated Water
• Industrial Water
• Irrigation Water
• Non-Corrosive Liquids
